HALE AP - Page 65

Parts Lists
Booster
Sec VI-9
2CBP PARTS LIST
Item # Part Number Qty Description
001-0230-00-0 1 2CBP PUMP BODY
1 & 2
001-0230-03-0 1 2CBP PUMP BODY BRONZE
002-0180-00-0 2CBP-2D HEAD-PUMP
3
002-0180-01-0
1
2CBP-2D HEAD-PUMP BRONZE
004-0091-00-0 CBP GEARBOX HSG
4
004-0380-00-0
1
40FW DRIVE UNIT HSG
007-0260-00-0 2CBP CROSS OVER TUBE
5
007-0260-01-0
1
2CBP CROSS OVER TUBE BRONZE
007-0270-00-0 2CBP-283 TUBE-DISCHARGE
6
007-0270-01-0
1
2CBP-283 TUBE-DISCHARGE BRONZE
007-0280-00-0 2CBP-75 ADAPTER-SUCTION
7
007-0280-01-0
1
2CBP-75 ADAPTER-SUCTION BRONZE
8 008-0150-00-0 1 CBP-61D BEARING-CAP
9 016-0270-00-0 1 2CBP-16F-6 1/2 IMPELLER-FRONT
10 016-0280-00-0 1 2CBP-16R-6 1/2 IMPELLER-REAR
11 017-0270-00-0 1 2CBP-17 KEY
12 017-0300-00-0 1 SSA-95XD KEY
13 017-0590-00-0 1 40FW DRIVE KEY
14 018-1404-02-0 12 SCREW-5/16-18 X 1/2 ZINC PL
15 018-1406-02-0 4 SCREW-5/16-18X3/4 PLD,
16 018-1410-02-0 2 SCREW-5/16-18X1 PLD
17 018-1607-02-0 8 SCREW-3/8-16X7/8 LG
018-1610-07-0 SCREW-3/8-16 X 1
18
018-1610-17-0
8
SCREW-3/8-16 X 1 BRONZE
018-1616-02-0 SCREW-3/8-16X1-3/4 ZINC PL
19
018-1616-17-0
8
SCREW,3/8-16 X 1-3/4 SST
018-1620-02-0 SCREW-3/8-16X2
20
018-1620-17-0
4
SCREW,3/8-16 X 2 SST
21 018-1644-02-0 2 SCREW-3/8-16X4-1/2 ZINC PL
22 018-2004-66-0 1 SCREW-1/2-13X1/2
23 018-5002-00-0 4 SCREW-#4 X 1/4 PLD,
