HALE HP300 - Oil Filter & Drain Assembly Identification (PL-11)

HP SERIES
PORTABLE PUMPS
USER OPERATION AND MAINTENANCE
70
6
7
3
6
5
2
1
4
8
9
10
12
11
PL-11: OIL FILTER AND DRAIN ASSEMBLY
ITEM PART NUMBER DESCRIPTION QTY UNIT
1 BAS-491056 OIL FILTER 1.0 EA
2 BAS-491657 OIL PRESSURE SWITCH 1.0 EA
3 218-0608-19-0 SCREW M6-1 X 16 SOC. HD. SST LOCK 3.0 EA
4 BAS-805449 WASHER 3.0 EA
5 BAS-805292 OIL FILTER HOLDER 1.0 EA
6 046-6600-00-0 GASKET-HP SERIES OIL FILTER 2.0 EA
7 005-1150-00-0 OIL FILTER ADAPTER-HP SERIES 1.0 EA
8 217-0201-04-0 PLUG-1/4 NPT HEX SOCKET HD BRS 1.0 EA
9 082-0302-90-0 OIL DRAIN BUSHING 1.0 EA
10 BAS-805030 SCREW 3.0 EA
11 018-5002-00-0 DRIVE SCREW OR RIVET 2.0 EA
12 101-0500-00-0 SERIAL NUMBER PLATE 1.0 EA
