HALE HP300 - HP X Series Mounting Hardware Identification (PL-12)

USER OPERATION AND MAINTENANCE
HP SERIES
PORTABLE PUMPS
71
PL-12: HP "X" SERIES MOUNTING HARDWARE
ITEM PART NUMBER DESCRIPTION QTY UNIT
1 210-0805-11-0 NUT M8-1.25 STNLS STL LOCKING 12.0 EA
2 097-1850-00-0 WASHER 1.13 OD X 0.34 ID X 0.091 IN. THK
ZINC PLTD STL 4.0 EA
3 218-0850-12-0 SCREW M8-1.25 X 100 H.H.ZINC PL 4.0 EA
4 097-0520-00-0 1-FZZ-264A RUBBER PAD #1019-2W 4.0 EA
5 048-1180-03-0 HANDLE SLEEVE BASE 4.0 EA
6 048-1180-01-0 HANDLE SLEEVE 4.0 EA
7 159-1350-00-0 SPACER 4.0 EA
5
3
4
6
2
1
7
