6
4. USAGE FOR THE AGE GROUP 2
Use of the harness system is only permitted for children of age Group I,
which means from 9kg to 18kg(approx. 9 months to approx. 4 years).
4.1 Setting the shoulder belt height(Group I)
Check whether the shoulder belts are set at the right height for your child.
The shoulder belts should be fed into the belt slots that lie at shoulder
height or just above.
If the height of your shoulder belts in child car seat is not t for your child,
Adjust the height of the shoulder belts, please proceed as follows:
Step 1: loosen the harness(see point 4.3) Turn the child seat to the
back(Fig. 1).
Step 2: Slide both of the harness off the harness connector (Fig. 2) .
To Next Page
