Figure11/Figure12/Figure13/Figure14: Pull out the power cable.
Connect the 3.5mm to DC power cable. Connect the power cable to
camera cable.
Figure17/Figure18: Secure the camera on bracket housing with
provided screws. Make sure the connections and the camera
antenna are secured tightly.
Fig.14Fig.13
Fig.16Fig.15
Fig.18Fig.17
-10-
