Haloview CA112 - Page 14

Figure7/Figure8: Ensure correct polarity when wiring the cables.
Red + Black -
Figure11/Figure12/Figure13: Wire connections and terminals must
be sealed securely and waterproof.
Fig.8Fig.7
Fig.10Fig.9
Figure9/Figure10: Clamp the terminal tightly to make sure they are
sealed and waterproof.
Fig.12Fig.11
Fig.13
-12-
