Appliance Ace HE24 Ace HE30 Ace HE35
Design Domestic Hot Water Ltr/min 9.8 12.3 14.3
Performance raised 35°C
(gpm) (2.2) (2.8) (3.1)
DHW Specific Rate (D) EN 625 Ltr/min 10.9 14.7 16.7
Min Mains Water Inlet Pressure for Max Heat Output Bar 1.0
(psi) (14.5)
Min Mains Water Inlet Pressure for Operation Bar 0.3
(psi) (4.4)
Max Mains Water Inlet Pressure Bar 10
(psi) (145)
Min Domestic Hot Water Flow Rate for Operation Ltr/min 2.0
(gpm) (0.45)
Min Central Heating System Pressure Bar 0.5
Max Central Heating System Pressure Bar 2.5
Max Domestic Hot Water Temperature °C 55
Min Domestic Hot Water Temperature °C 40
Max Central Heating Flow Temperature °C 80
Min Central Heating Flow Temperature °C 30
Connections
Ace HE24 Ace HE30 Ace HE35
Gas 15 mm compression 22 mm compression
CH flow 22 mm compression
CH return 22 mm compression
DHW inlet 15 mm compression
DHW outlet 15 mm compression
Pressure relief valve outlet 15 mm compression
Condensate Drain 21.5 - 22 mm plastic overflow pipe
2.3
GENERAL SPECIFICATIONS
NOTE: THE STATED HEAT INPUT AND CO
2
VALUES ARE NOMINAL AND MAY VARY BY ± 5-10% WHEN THE APPLIANCE IS
RUN WITH LINE GAS, DUE TO FLUCTUATIONS IN GAS QUALITY.
Appliance Ace HE24 Ace HE30 Ace HE35
Total weight (full) kg 45.1 51.7 51.7
Total weight (empty) kg 43.0 49.0 49.0
Max lift weight kg 42.0 48.0 48.0
Total water capacity Ltr 1.8 2.1 21.1
Integral expansion vessel capacity Ltr 8
Maximum heating system water content
using fitted expansion vessel, @ 0.75 bar
Ltr 84
Electrical supply 230V 50Hz Fuse at 3A
Internal fuse T4H 4A 250V
Maximum power consumption W 140 160 145
IP Rating IP20
Flue gas temperature Nat Gas 50/30 °C 53 49 56
CO
2
value max rate (Nat Gas) (G20) %
9.2 ± 0.3 case on
9.0 ± 0.2 case off
CO
2
value min rate (Nat Gas) ref only (G20) % 8.6 ± 0.3 8.6 ± 0.3 8.6 ± 0.3
CO/CO
2
Ratio max rate (Nat Gas) (G20) 0.0005 + 0.005 0.0003 + 0.005 0.0003 + 0.005
Flue products mass flow rate (Nat Gas) (G20) g/s 14.7 11.0 16.0
Gas Valve Offset @ min rate Pa -5.0
