Hammerhead SS250 - Page 55

STEERING SHAFT ASSY.
REF NO.
PART NO. DESCRIPTION
1
7.010.041 STEERING BOLT COVER
2
9.100.612 BOLT STRAP M6x12
3
8.030.024 SPINDLE BRACKET
4
7.020.038 STEERING WHEEL
5
6.000.122 STEERING SHAFT
6
7.010.026 STEERING SHAFT BUSH
7
9.700.020 SPECIAL WASHER
8
9.700.120
CIRCLIP
4)20
9
9.100.825 BOLT M8x25
10
9.400.008 LOCK WASHER
11
6.000.093-250 STEERING KNUCKLE
12
4.000.008-250 STEERING GEAR 45 DEGREE ANGLE
13
9.108.025 BOLT-WASHER M8x1.25x25
14
9.900.016 ROUND NUT M16x1.5
15
4.000.008 STEERING BALL JOINT
16
9.200.010 NUT M10
17
7.020.002 BALL JOINT DUST COVER
18
8.010.157-250 TIE ROD
19
6.000.062 ROD END
20
9.300.010 FLAT WASHER
21
9.400.010
LOCK WASHER 4,10
22
9.800.010 CASTLE NUT M10
23
9.500.215 COTTER PIN
24
7.020.066 STEERING KNUCKLE DUST COVER
25
8.020.014 STEERING GEAR BRACKET
26
9.220.008 LOCKING FLANGE NUT M8
27
9.708.145 TUROTTLE PEDAL BOLT M8x1.25x145
28
8.040.001 THROTTLE PEDAL RETURN SPRING L.
29
9.108.040 BOLT-WASHER M8x1.25x40
30
9.200.008 NUT M8
31
4.000.016 THROTTLE PEDAL COMP.
32
9.600.515 PAN SCREW M5x15
33
9.300.005 FLAT WASHER
34
9.210.005 NYLON LOCK NUT M5
35
4.000.015 BRAKE PEDAL COMP.
36
9.700.624 PIN
37
8.010.081 SPINDLE PIN
38
9.500.212 COTTER PIN 12x12
39
6.000.063 BRAKE LAMP SWITCH ASSY.
40
9.600.306 PAN SCREW M3x6
41
7.010.004 PEDAL BUSH
42
8.040.007 BRAKE PEDAL RETURN SPRING,R.
