Hammerhead SS250 - Page 57

FRONT SUSPENSION ARM ASSY.
REF NO.
PART NO.
1
2.000.028-B STRUT AND SPINDLE SUPPORT R.-BLACK
1
2.000.028-SS STRUT AND SPINDLE SUPPORT R. With Bracket-BLACK
2
9.108.105 BOLT-WASHER M8x1.25x105
3
8.010.015 UPPER SUSPENSION ARM COLLAR
4
7.010.003 UPPER SUSPENSION ARM BUSH
5
4.000.004 UPPER SUSPENSION ARM
6
9.220.008 LOCKING FLANGE NUT M8
7
9.800.012 CASTLE NUT M12
8
7.020.025 BALL HEAD DUST SEAL
9
8.020.053 BALL HEAD SPACER
10
2.000.027-B STRUT AND SPINDLE SUPPORT L.-BLACK
10
2.000.027-SS STRUT AND SPINDLE SUPPORT L with Bracket.-BLACK
11
9.908.104 BOLT STRAP M8x14
12
8.010.014 LOWER SUSPENSION ARM COLLAR
13
9.906.012 BOLT STRAP M6x12
14
6.000.141B FR.WHEELASSY. R.20x7-8
15
7.020.016 FR.BRAKE CALIPER PAD SET.
16
6.000.028 FRONT BRAKE CALIPER L.
17
8.010.054 BRAKE DISC.
18
9.040.002 DUST SEAL 47x25-7
19
9.030.002-Z BEARING 6204-Z
20
9.710.031
TIRE BOLT M10x1.25x31
21
8.010.085 WHEEL HUB
22
9.030.010-Z BEARING 6202-Z
23
8.010.118 CAP LUG NUT M10
24
7.020.050 TIRE FR.20x7-8
25
6.000.142B RIM,FR.
26
9.220.010 LOCKING FLANGE NUT M10
27
9.800.014 CASTLE NUT M14
28
9.500.220 COTTER PIN
29
7.020.039 HUB COVER
30
9.110.040 BOLT-WASHER M10xl.25x40
31
6.000.095 FRONT BRAKE CALIPER R.
32
6.000.325 CUSHION ASSY.,FR.L=325
33
9.110.080 BOLT-WASHER M1Oxl.25x80
34
8.020.034 LOWER SUSPENSION ARM DUST CAP
35
7.010.002 LOWER SUSPENSION ARM BUSH
36
9.040.001 O-RING
37
4.000.023 LOWER SUSPENSION ARM ASSY.
38
6.000.140B FR.WHEELASSY. L.20x7-8
39
8.010.140 ACORN NUT M12
40
9.500.200 COTTER PIN
