Hammerhead SS250 - Page 59

FULL SHIFTING ASSY.
REF NO.
PART NO. DESCRIPTION
1
9.908.055N BOLT-WASHER M8x55
2
9.111.100 BOLT-WASHER M12x121
3
6.100.240 GEAR BOX SUSPENSION ARM
4
8.010.168 COLLAR #1
5
9.112.230 BOLT-WASHER M12x1.25x230
6
6.000.239 PIVOT ARM SHIFT C
7
7.020.068 CUSHION BUSH
8
9.220.012 LOCKING FLANGE NUT M12
9
8.010.167 COLLAR #2
10
9.112.190
BOLT-WASHER Ml2x1.25x190
11
6.000.238 PIVOT ARM SHIFT B
12
9.110.200
BOLT-WASHER MIOx1.25x200
13
9.220.010 LCOKING FLANGE NUT M10
14
6.100.237 PIVOT ARM SHIFT A
15
7.010.004 PEDAL BUSH
16
9.108.145 BOLT M8x1.25x145
17
6.000.235 RIGHT TURN CLEVIS ROD HEAD
18
9.110.030 BOLT-WASHER M10x30
19
6.100.001 PIVOTARMSHIFTD
20
6.100.236 SHORT CLEVIS ROD
21
9.200.010-L LEFT TURN NUT M10
22
9.220.008 LOCKING FLANGE NUT M8x1.25
23
9.110.040 BOLT-WASHER M10x40
24
6.000.233 LONG CLEVIS ROD
25
9.700.513
PIN (05x13.5
26
9.500.212 COTTER PIN
27
4.000.031 SHIFTER HOUSE ASSY.
28
9.100.612 BOLT M6x12
29
6.000.258 PARKING BRAKE ASSY.
30
9.108.020 BOLT-WASHER M8x20
31
9.300.008 WASHER 48
32
9.300.010 WASHER 4 10
33
9.110.080 BOLT M1Ox1.25x80
34
8.110.043 COLLAR
35
7.120.001 CUSHION BUSH
36
9.220.014 LOCKING FLANGE NUT M14x1.5
37
8.110.042 WASHER ENGINE MOUNT LINK
38
7.120.001 CUSHION ENGINE MOUNT LINK
39
8.120.045 SPACER ENGINE MOUNT LINK
40
8.110.041 COLLAR ENGINE MOUNT LINK
41
6.1000.026 ENGINE MOUNT BOLT PLATE
42
9.110.091 BOLT M1Ox1.25x91
43
7.010.004 PEDAL BUSH
44
4.000.031-250 SHIFTER RELEASE CABLE
