Hammerhead SS250 - Page 61

REAR CARGO RACK/SEAT/BELT
REF NS.
PART NO.
1
9.090.005 TAIL LIGHT BULB 21 W/5W 12V
2
6.000.144 TAIL LIGHT
3
9.210.006 LOCK NYLON NUT M6
4
2.100.046-B REAR CARGO RACK B.S.(BLUE)
4
2.100.046-S REAR CARGO RACK B.S.(SILVER)
4
2.100.046-BL REAR CARGO RACK B.S.BLACK
5
6.000.111 REAR SIDE REFLECTOR
6
8.010.171 LUG NUT
7
7.020.032 TUBE COVER
8
6.000.241 LICENSE LIGHT ASSY.
9
9.804.003 SCREW 8T3.5x10
10
9.220.008 LOCK FLANGE NUT M8
11
6.000.146 FUEL TANK CAP COMP
12
4.000.029-C FUEL TANK COMP. B.S.CARBON
12
4.000.029-O FUEL TANK COMP. B.S.ORANGE
12
4.000.029-R FUEL TANK COMP. B.S.RED
12
4.000.029-B FUEL TANK COMP. B.S.BLUE
12
4.000.029-P FUEL TANK COMP. PURPLE
12
4.000.029-BL FUEL TANK COMP. B.S.BLACK
12
4.000.029-G FUEL TANK COMP. B.S.GREEN
13
9.108.025 BOLT-WASHER M8x1.25x25
14
8.010.034 TANK COMP.COLLAR
15
7.020.005 RUBBER MOUNT
16
9.300.008
FLAT WASHER 4,8
17
6.000.046-250 FUEL AUTO COCK ASSY.-ON/OFF VALVE
18
6.000.056 GAS FILTER
19
7.020.030 TUBE COMP.FUEL#1
20
7.020.029 TUBE COMP.FUEL#2
21
7.020.031 TUBE COMP.VA000M
22
6.000.146 SAFETY BELT
23
6.000.262 HEAD-REST
24
6.000.264 SEAT COMP.L.
25
9.700.001
SPECIAL BOLT M7/160
x28
26
9.700.002 BELT WASHER
27
9.700.003 NUT BELT M7/A6'
28
9.900.840 BOLT STRAP M8x1.25x40
29
9.220.008 LOCK FLANGE NUT M8
30
6.000.057 SEAT RAIL SET
31
8.040.008 VACUUM TUBE
32
8.040.009 FUEL TUBE
33
6.000.263 SEAT COMP.R.
34
8.010.047 R-WASHER
35
9.908.066 BOLT STRAP M8x1.25x65
36
4.000.036 MAIN SPEAKER
37
4.000.037 AUXILIARYSPEAKER
