Hammerhead SS250 - Page 63

AIR CLEAN GE/RADIATOR/ BATTERY/ MUFFLER ASSY.
REF NO.
PART NO. DESCRIPTION
1
7.090.035 AIR CLEANER DUCT
2
7.090.036 AIR CLEANER CLAMP
3
7.190.037 AIR CLEANER CASE COMP.
4
7.090.038 AIR CLEANER ELEMENT
5
7.190.039 AIR CLEANER COVER
6
9.805.003 TAPPING SCREW M5x16
7
7.090.040 AIR CLEANER GAUZE COVER
8
7.090.041 AIR CLEANER ELEMENT GAUZE
9
4.100.032 AIR CLEANER ASSY.
10
7.090.042 TUBE COMP.WATER 1#
11
7.190.043 TUBE COMP.WATER 2#
12
7.090.044 TUBE CLAMP
13
7.090.045 TUBE COMP.WATER 3#
14
7.090.046 TUBE COMP.WATER4#
15
9.100.830 BOLT M8x3Ox1.25
16
7.090.047 RADIATOR COMP.COLLAR
17
7.020.069 RUBBER MOUNT
18
9.200.008 NUT M8
19
6.000.248 COLLANT TANK
20
7.010.028 BATTERY COVER
21
6.000.085 BATTERY YTx12-BS
22
7.021.023 BATTERY BAND
23
7.020.020 BATTERY LOWER
24
7.090.049 MUFFLER COMP.EX.
25
9.040.027 MUFFLER JOINT NUT M6
26
7.090.050 EX.PIPE GASKET
27
9.110.030
BOLT-WASHER MlOx1.25x30
28
9.020.010 NUT M10
29
4.000.033 RADIATOR COMP.
30
7.090.051 TUBE CLAMP
31
9.200.006 NUT M6
32
6.100.249 FAN COMP.
33
7.090.052 BOLT
34
2.100.047 250CC ENGINE
35
7.090.053 TUBE COMP WATER 5#
36
7.090.054 TUBE COMP WATER 6#
37
7.090.055 TUBE COMP WATER 7#
38
7.090.056 TUBE COMP WATER 1#
39
7.090.057 TUBE COMP WATER 2#
40
4.000.034 RADIATOR.COMP
41
9.100.625 BOLT M6x25
42
6.100.162 BOOT.SIDE CASE
43
8.120.055 CLAMP.BOOT
44
8.020.166Ͳ25
0
250CCMUFFLERCLAMP
