REAR SUSPENSION ASSY.
REF NO.
PART NO.
1
7.020.039 RR.HUB COVER
2
9.500.430
COTTER PIN
44x30
3
9.800.018 CASTE NUT M18
4
8.010.118 LUG NUT CAP M10
5
6.000.143B RIM RR.
6
8.010.169-250 REAR WHEEL HUB
7
9.710.031
TIRE BOLT M10x1.25x31
8
9.030.007-250 BEARING 6007
9
8.010.170-250 COLLAR
10
9.112.055 BOLT-WASHER M12x1.25x55
11
9.220.012 LOCKING FLANGE NUT M12x1.25x50
12
9.112.050 BOLT-WASHER M12x1.25x50
13
7.020.008 SWING ARM CUSHION BUSH
14
6.000.242 BALANCE LEVER LINK ROD
15
9.220.010 LOCKING FLANGE NUT M10x1.25
16
6.000.243 BALANCE LEVER
17
9.108.020 BOLT-WASHER M8x20x1.25
18
8.010.053-SS RR.BRAKE DISC. W/SPEEDO MAGNET HOLE
19
8.030.036 BRAKE DISC.BASE
20
9.101.018 BOLT M10x1.5x18
21
7.020.022-250 RR.BRAKE PAD SET.
22
6.000.229-250 CALIPER HYDRAULICAL BRAKE,RR.
23
9.908.014 ALLEN HEAD BOLT M8x1.25x16
24
6.000.244 CV/SHAFT JOINT
25
6.000.245 CUSHION ASSY.,RR.L=480
26
6.000.247 SWING ARM COMP.R.
27
6.000.246 SWING ARM COMP.L.
28
9.040.011 DUST SEAL
29
6.000.148B REAR WHEEL ASSY.,R.
30
6.000.147B REAR WHEEL ASSY.,L.
31
7.020.052 TIRE.RR.22x10-10
32
9.906.016 BOLT-WASHER M6x16
33
7.010.064 FENDER,RR.
34
6.100.068 REAR FENDER BRACKET.R.
35
6.100.101 REAR FENDER BRACKET L.
36
9.108.045 BOLT-WASHER M8x1.25x45
37
9.170.002 CHAIN O-RING DRIVE
38
8.130.033 HOUSING COMP.RRAXLE BRG
39
9.030.007-250 BEARING E6007
40
8.110.057 AXLE
41
8.110.077 REAR SPROCKET
42
9.112.030 BOLT-WASHER
43
9.112.025 BOLT-WASHER
44
6.000.244ͲC REARAXLECIRCLIP
45
6.200.068 REARFENDERBRACKETR.2BOLTMOUNT
