Hammond SK1 User Manual

143
Appendix
Drawbar Data List 1
Control Number
Upper: 50H(80)
Lower: 51H(81)
Pedal: 52H(82)
Upper / Lower Pedal
Level 16´ 5 ⁄´ 8´ 4´ 2 ⁄´ 2´ 1 ⁄´ 1 ⁄´ 1´ 16´ 8´
0
00H(0) 09H(9) 12H(18) 1BH(27) 24H(36) 2DH(45) 36H(54) 3FH(63) 48H(72) 00H(0) 09H(9)
1
01H(1) 0AH(10) 13H(19) 1CH(28) 25H(37) 2EH(46) 37H(55) 40H(64) 49H(73) 01H(1) 0AH(10)
2
02H(2) 0BH(11) 14H(20) 1DH(29) 26H(38) 2FH(47) 38H(56) 41H(65) 4AH(74) 02H(2) 0BH(11)
3
03H(3) 0CH(12) 15H(21) 1EH(30) 27H(39) 30H(48) 39H(57) 42H(66) 4BH(75) 03H(3) 0CH(12)
4
04H(4) 0DH(13) 16H(22) 1FH(31) 28H(40) 31H(49) 3AH(58) 43H(67) 4CH(76) 04H(4) 0DH(13)
5
05H(5) 0EH(14) 17H(23) 20H(32) 29H(41) 32H(50) 3BH(59) 44H(68) 4DH(77) 05H(5) 0EH(14)
6
06H(6) 0FH(15) 18H(24) 21H(33) 2AH(42) 33H(51) 3CH(60) 45H(69) 4EH(78) 06H(6) 0FH(15)
7
07H(7) 10H(16) 19H(25) 22H(34) 2BH(43) 34H(52) 3DH(61) 46H(70) 4FH(79) 07H(7) 10H(16)
8
08H(8) 11H(17) 1AH(26) 23H(35) 2CH(44) 35H(53) 3EH(62) 47H(71) 50H(80) 08H(8) 11H(17)
ex: Set Lower 8´ to level 7 via MIDI... Bx 51 19 (x=Lower Channel)
Drawbar Data List 2
Control Number
Part 16´ 5 ⁄´ 8´ 4´ 2 ⁄´ 2´ 1 ⁄´ 1 ⁄´ 1´
Upper
0CH(12) 0DH(13) 0EH(14) 0FH(15) 10H(16) 11H(17) 12H(18) 13H(19) 14H(20)
Lower
15H(21) 16H(22) 17H(23) 18H(24) 19H(25) 1AH(26) 1BH(27) 1CH(28) 1DH(29)
Pedal
21H(33) - 23H(35) - - - - - -
Level
012345678
Value
00 - 0FH
(0 - 15)
10 - 1FH
(16 - 31)
20 - 2FH
(32 - 47)
30 - 3FH
(48 - 63)
40 - 4FH
(64 - 79)
50 - 5FH
(80 - 95)
60 - 6FH
(96 - 111)
70 - 7EH
(112-126)
7FH
(127)
ex: Set Lower 8´ to level 7 via MIDI... Bx 17 70 (x=Upper Channel)

Hammond SK1 Specifications

General

Type	Portable Keyboard
Extra Voice Section	Electric Piano, Clavinet
Effects	Reverb, Chorus, Overdrive
Leslie Simulation	Yes
Connections	MIDI In/Out, USB
Power Supply	AC adapter (included)
Manuals	61 keys
