Hammond SK1 User Manual

19
Hook-Up
1. Connect as illustrated.
NOTE: This illustration shows only the keyboard expansion. See P. 16 for the basic hook up of the
power source, audio, etc.
2. Switch ON the power of this unit.  en recall the MIDI template “Extra Voice”. (P.
114)
Refer to the operation manual of the added MIDI keyboard as required.
PHONES
USB MEMORY
Weighted
MIDI Keyboard
MIDI OUT
SK1: ORGAN + PIANO
You can create a comprehensive basic keyboard rig by utilizing a separate keyboard con-
troller for the Extra Voices (Piano, Etc) and using the SK-1 keyboard for Organ.

Hammond SK1 Specifications

General

Type	Portable Keyboard
Extra Voice Section	Electric Piano, Clavinet
Effects	Reverb, Chorus, Overdrive
Leslie Simulation	Yes
Connections	MIDI In/Out, USB
Power Supply	AC adapter (included)
Manuals	61 keys
