HAMPTON BAY 100 - Assembling the Side Panel with Window; Assembling the Gas Tank Support

8
3
Assembling the side panel with
□ Attach the side panel with window (F) to the stands
using four (4) M6 x10 mm bolts (AA).
□ Do not tighten the bolts at this step.
4
Assembling the gas tank support
□ Attach the gas tank support (J) to the stands using four (4)
M6 x 10 mm bolts (AA).
□ Tighten the bolts (AA) with a Phillips screwdriver (not
included).
Assembly (continued)
J
window
F
AA
AA
