Assembly (continued)
8
Assembling the back panel
□ Fasten the back panels (H) to the assembled unit using thirty-seven screws (i) , Do not over tighten the screws.
□ Opening the safety strap kit , screw the washer and strap to the back panel (H) as the picture showing below.
C
B
H
Before attaching the back panel be sure
that the unit is at 90°
i
