HAMPTON BAY Espresso - Pre-Assembly Steps; Planning Assembly Steps; Tools and Hardware Required

3
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
PLANNING ASSEMBLY
Compare all parts with the Hardware Included and Package Contents lists in this manual. If any part appears missing or damaged, do not
assemble this product. Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
TOOLS REQUIRED
Flathead
screwdriver
Phillips
screwdriver
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
a
a
a
21
21
20
8
4
2
40
6
37
2
1
Cam Lock
Cam Bolt
Wood Dowel
Shelf Support
Bolt
Knob
3.5*14 mm Screw
Hinge
3*14 mm Screw
Rod Holder
Safety Strap Kit
b
c
d
e
f
g
h
i
j
f g h i j
b
c d e
Safety Strap Kit
