15
Assembly (continued)
11
Securing the cabinets to the wall
□ Drill a 3/16" diameter hole (5mm) in the wallboard. Tap the wall
anchor into the hole until it is flush. Fasten the safety strap to
the wall anchor with the long screw.
WEIGHT LIMITS (option)
□ This unit has been designed to support the maximum loads shown.
Exceeding these load limits could cause sagging, instability,
product collapse, and/or serious injury.
WARNING: Please ensure that all the objects are removed
before moving the assembled unit. The unit must be lifted
by more than one person, not dragged or pushed. Failure
to do so will cause product damage, instability, product
collapse, and/or serious injury.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
hanging rod
15 lbs
40 lbs
0 lbs
15 lbs
15 lbs
30 lbs
A
