HAMPTON BAY Mena - Attaching Light Kit Assembly

12
Assembly - Attaching the Accessories
Attaching the light kit tter assembly
1
□ Connect the wires from the light kit assembly (G) to the wires
from the fan motor assembly (E) by connecting the molded
adaptor plugs together. Carefully tuck all wires and splices
into the switch cup and connect the safety cable (SS) from the
light kit assembly (G) to the hook from motor assembly (E).
□ Push the light kit assembly (G) up to the motor assembly (E)
by aligning the magnet part of the motor assembly (E) till it is
secure.
E
G
SS
Hook
