Attaching the side panels into the face frame
Start by placing the face frame (A) flat on a smooth surface that will not scratch or damage the face of the cabinet, such as a
towel or piece of cardboard (1) from the packaging.
NOTE: Identification: Face frame /Side panels of BASE CABINET are longer than Face frame /Side panels of TOP CABINET.
Install the two side panels (B) into the mating grooves on the face
frame (A) by: aligning the wooden dowels & male connectors on side
panel (B) to the holes & female connectors on face frame (A).
Use both hands to firmly press the side panels (B) down at all
locations with connectors to ensure they lock together tightly.
IMPORTANT: There will be a “clicking” sound when the connectors lock together properly
Repeat these steps for the front (F) and sides (G) of the Base Cabinet
