1 Introduction
1.1 Product description
The product is a portable car lift with 2 rails and a hydraulic
unit that is used to lift cars. It is powered by a standard wall
outlet. Do not use the product for other tasks.
1.2 Symbols
Read the operating instructions carefully
and make sure that you understand the
instructions before you use the product.
Save the instructions for future reference.
This product complies with applicable EU
directives and regulations.
Recycle as electrical waste.
1.3 Product overview
(Figure 1)
1. Filler plug for hydraulic fluid
2. Hydraulic fluid container
3. Remote control
4. Hydraulic unit
5. Long hydraulic hoses with couplers (X2)
6. Safety lock bar (X2)
7. Lifting frames (X2)
8. Short hydraulic hoses with couplers (X2)
9. Positioning handle
10. Rubber lifting blocks 55mm (X4) and 75mm (X4)
11. Seal plug for hydraulic container
12. Teflon tape
2 Safety
2.1 Safety definitions
Warning! If you do not obey these instructions, there
is a risk of death or injury.
Caution! If you do not obey these instructions, there
is a risk of damage to the product, other materials or the
adjacent area
Note! Information that is necessary in a given situation.
Table of Contents
1 Introduction 27
1.1 Product description ............................................................27
1.2 Symbols .................................................................................. 27
1.3 Product overview ...............................................................27
2 Safety 27
2.1 Safety definitions ................................................................27
2.2 Safety instructions for operation ...............................28
2.3 Personal protective equipment ..................................29
3 Assembly 29
3.1 To install the product ........................................................ 29
4 Operation 29
4.1 To examine before each use ......................................... 29
4.2 To fill hydraulic fluid ......................................................... 29
4.3 To lift and lower the product........................................29
4.4 To use the product ............................................................ 29
4.5 Lifting frame .........................................................................29
4.6 To put the lifting frames in position below the
vehicle ................................................................................................30
4.7 Safety lock bars ..................................................................30
4.8 To lift the vehicle ................................................................30
4.9 To lower the lifting frames from the locked
position ............................................................................................... 31
5 Maintenance 31
5.1 To lubricate the product ...................................................31
5.2 To clean the product ......................................................... 31
5.3 To repair the product ........................................................31
6 Troubleshooting 32
7 Transportation 33
7.1 To do before transportation ...........................................33
8 Storage 33
8.1 To put the product in storage ....................................... 33
9 Disposal 33
9.1 To discard the product ..................................................... 33
10 Technical data 33
