31
2022_001
11 Do a visual check that the 2 locking frames are
locked at the same locking position. Make sure that
the lifting blocks touch the lifting points of the
vehicle.
4.9 To lower the lifting frames from
the locked position
Warning! When you lower the lifting frames, make
sure that the safety lock bar and the turning block stay in
their tracks. If they are put to the side, they may become
stuck. That may result in that the lifting frame does not lower
correctly.
1 Push and hold the U button until the lock bar is out
from the lock block.
2 Lift the 2 lock bars on the 2 lift frames. Make sure that
the turning block (B) is on top of the lock block If it is
necessary, use a tool to lift the lock bars. (Figure 11)
3 Push and hold the D button. Make sure that the lock
bars do not go into the lock block. If it is necessary,
release the D button and do the steps 1-3 again.
4 When the lifting frames are lowered to the ground,
hold the D button for a few seconds more and then
release it.
Note! When the lifting frames are on the ground and the
D button is pushed, the hydraulic fluid returns to the fluid
container.
5 Hold the frame handles and remove the lifting frames
from the working area.
6 Move the vehicle. Make sure not to drive over the
lifting frames and the hydraulic hoses.
5 Maintenance
Warning! Pull out the power plug and release the hy-
draulic pressure before you do maintenance of the product.
5.1 To lubricate the product
● Do a check of all joints each month. If it is necessary,
lubricate with white lithium grease. (Figure 12)
5.2 To clean the product
● Clean all parts regularly.
● Use personal protective equipment when you do work
with the hydraulic system. Refer to “2.3 Personal
protective equipment” on page 29.
● Do not let your skin touch hydraulic fluid. Refer to the
safety instructions from the hydraulic fluid manufacturer.
● Speak to a doctor in the event of that hydraulic fluid
touch your skin, or get into the blood-stream.
5.3 To repair the product
Let an approved service center do the repair of the product.
The warranty will be invalidated if the product is modified in
any way, damaged as a result of an accident, negligence or
incorrect use, or if it has been repaired by unauthorized
personnel.
