Hamron 608201 - Technical Data; Description of Components; Charging Modes and Current Settings; Display Indicators and Symbols

21
EN
TECHNICAL DATA
Input voltage 230 V
~
50 Hz
Input current 0.6 A
Charging voltage 12 VDC
6 VDC
Charging current 1–4 A
Battery capacity Min. 1.2 Ah – Max 120 Ah
Protection rating IP65
Dimensions 160 x 55 x 45 mm
Weight 0.5 kg
DESCRIPTION
1. Charging current 12 V standard lead-acid battery: 1A/2A/3A/4A.
The charging current is set automatically, depending on the battery
capacity and/or charging.
2. Charging current 12 V AGM battery: 1A/2A/3A/4A. The charging
current is set automatically, depending on the battery capacity and/
or charging.
