Hanbell RC2-100A - Page 5

Technical Manual VERSION 2.0 -10-18-2018
5

 


b. RC2B
MODEL
COMPRESSOR MOTOR
Lubricant
charge
Oil
Hydrostatic
Pressure
Test
WEIGHT
Displacement
60 / 50Hz
Rated
Speed
VI
Cap. Control (%)
Type
Nominal Hp
Starting
Voltage (V)
Insulation Protection
Heater
m
3
/hr 60 / 50Hz STEP STEPLESS 60Hz 50Hz 60Hz 50Hz L W Kg/cm2G kg
RC2100B
118/98
3550/2950
2.2
2.6
3.0
3.5
4.8
33, 66, 100 33~100
3 Phase, 2 Pole, Squirrel Cage, Induction Motor
38 31
Y△
△△
△
PWS
DOL
208
220
230
380
440
460
480
575
380
400
415
Class F
PTC Protection
7
150/300 42
280
RC2140B
165/137 33, 66, 100 33~100 50 41 7 285
RC2180B
216/180 33, 66, 100 33~100 66 55 7 335
RC2200B
233/193 25, 50, 75, 100 25~100 70 58 8 425
RC2230B
277/230 35, 50, 75, 100 35~100 81 67 14 555
RC2260B
309/257 25, 50, 75, 100 25~100 90 75 14 560
RC2300B
352/293 25, 50, 75, 100 25~100 107 89 16 600
RC2310B
371/308 35, 50, 75, 100 35~100 110 91 16 580
RC2320B
384/320 25, 50, 75, 100 25~100 114 94 16 600
RC2340B
407/339 35, 50, 75, 100 35~100 121 101 16 620
RC2370B
440/366 35, 50, 75, 100 35~100 130 108 16 640
RC2410B
490/407 25, 50, 75, 100 25~100 146 121
380
440
460
480
575
16 740
RC2470B
567/471 25, 50, 75, 100 25~100 170 141 18 810
RC2510B
611/508 35, 50, 75, 100 35~100 183 152 20 780
RC2550B
660/549 25, 50, 75, 100 25~100 195 162 23 850
RC2580B
702/583 35, 50, 75, 100 35~100 210 175 20 840
RC2620B
745/619 35, 50, 75, 100 35~100 220 183
Y△
△△
△
DOL
23 880
RC2710B
858/713 35, 50, 75, 100 35~100 250 208 28 1099
RC2790B
952/791 30, 50, 75, 100 30~100 276 230 28 1180
RC2830B
993/825 30, 50, 75, 100 30~100 290 234 28 1215
RC2930B
1117/929 35, 50, 75, 100 35~100 334 278 28 1240
RC21020B
1223/1017 25, 50, 75, 100 25~100 357 297 40 1540
RC21130B
1350/1122 25, 50, 75, 100 25~100 393 327 40 1560
RC21270B
1521/1268 25, 50, 75, 100 25~100 471 392 53 2200
RC21530B
1847/1539 25, 50, 75, 100 25~100 534 443 53 2300
Nominal Horse Power:
All above Nominal Hp are not equal to the maximum compressors Hp; Please refer to Hanbell selection software’s
output for the rated current, Maximum Continuous CurrentM.C.C according to various working condition while
selecting the contactor, cable, fuse and wire, etc
