Parts of the wheelchair
In order to be able to read and understand this manual it is important that you fa-
miliarise yourself with the most common terms that we use for the different parts
of the wheelchair.
Have a look at fi gure 1 and note the relevant parts on your wheelchair.
The equipment on your wheelchair may vary slightly from the fi gure shown.
Backrest with backrest
cover
Armrests
Clothing guards
Seat
Leg support
Frame
Footplate
Pushing handle
Driving wheels
Hand rim
Brake
Wheel block
Front castor wheel fork
Front castor wheel
Figure 1
