Handicare MINIVATOR 2000 - MS125 2000 DIP Settings (Auto Hinge)

MS125 2000 DIP Settings LH Auto Hinge CSE126
1 2 3 4
1 2 3 4
IF ANY DIP SWITCHES ARE CHANGED, PLEASE
TURN OFF LIFT, WAIT 10 SECONDS, THEN
POWER THE LIFT BACK ON.
INFRARED/RADIO
LEARN BUTTON
DIP SWITCH 2
FRONT PANEL
LED CONNECTION
BRAKE
CONNECTOR
CHARGE +
BATTERY POSITIVE BATTERY NEGATIVE
MOTOR 2
MOTOR 1
HINGE DATA
(GREY CABLE)
+24V FUSED
INFRARED/
RADIO
NO CONNECTION
REQUIRED
DIP SWITCH 1
(BLACK)
(WHITE)
DIAGNOSTIC
DISPLAY
EXTERNAL DIAGNOSTIC
HINGE SAFETY
SWITCH INPUT
9 WAY CONNECTOR8 WAY CONNECTOR
ON
ON
M
5A
QUICK BLOW
ON
1 2 3 4
ON
1 2 3 4
SLIDE ENABLE PING ENABLE PLATFORM ENABLE AUTO HINGE ENABLE RIGHT HAND LIFT FAST RAMP UNUSED
DIP 1 DIP 2
DEFAULT OFF
SLIDE DISABLE
PING DISABLE
PLATFORM DISABLE
AUTO HINGE DISABLE
LEFT HAND LIFT
SLOW RAMP
UNUSED
DIP SWITCH SETTING CSE125SM
DIP SWITCH SETTING CSE126
ON
1 2 3 4
THIS SETTING WILL ENABLE 2000 HINGE
MODE AND ALSO SET THE CURRENT LIMIT
FOR AN RTC HINGE
WHITE BLUE BROWN BROWN N/C N/C GREY YELLOW N/C N/C ORANGE ORANGE YELLOW YELLOW WHITE N/C WHITE
MS125 2000 DIP Settings RH Auto Hinge CSE126
1 2 3 4
1 2 3 4
IF ANY DIP SWITCHES ARE CHANGED, PLEASE
TURN OFF LIFT, WAIT 10 SECONDS, THEN
POWER THE LIFT BACK ON.
INFRARED/RADIO
LEARN BUTTON
DIP SWITCH 2
FRONT PANEL
LED CONNECTION
BRAKE
CONNECTOR
CHARGE +
BATTERY POSITIVE BATTERY NEGATIVE
MOTOR 2
MOTOR 1
HINGE DATA
(GREY CABLE)
+24V FUSED
INFRARED/
RADIO
NO CONNECTION
REQUIRED
DIP SWITCH 1
(WHITE)
(BLACK)
DIAGNOSTIC
DISPLAY
EXTERNAL DIAGNOSTIC
HINGE SAFETY
SWITCH INPUT
9 WAY CONNECTOR8 WAY CONNECTOR
ON
ON
M
WHITE BLUE BROWN YELLOW N/C N/C GREY VIOLET N/C N/C ORANGE ORANGE YELLOW YELLOW WHITE N/C WHITE
5A
QUICK BLOW
ON
1 2 3 4
ON
1 2 3 4
SLIDE ENABLE PING ENABLE PLATFORM ENABLE AUTO HINGE ENABLE RIGHT HAND LIFT FAST RAMP UNUSED
DIP 1 DIP 2
DEFAULT OFF
SLIDE DISABLE
PING DISABLE
PLATFORM DISABLE
AUTO HINGE DISABLE
LEFT HAND LIFT
SLOW RAMP
UNUSED
DIP SWITCH SETTING CSE125SM
DIP SWITCH SETTING CSE126
ON
1 2 3 4
THIS SETTING WILL ENABLE 2000 HINGE
MODE AND ALSO SET THE CURRENT LIMIT
FOR AN RTC HINGE
44 MINIVATOR 2000 INSTALLATION MANUAL
Appendix 3
MS125 2000 DIP settings LH auto hinge CSE126
MS125 2000 DIP settings RH auto hinge CSE126
