Handicare MINIVATOR 2000 - MS125 2000 DIP Settings (Auto Swivel)

MS125 2000 DIP Settings LH Auto Swivel System
1 2 3 4
1 2 3 4
IF ANY DIP SWITCHES ARE CHANGED, PLEASE
TURN OFF LIFT, WAIT 10 SECONDS, THEN
POWER THE LIFT BACK ON.
INFRARED/RADIO
LEARN BUTTON
DIP SWITCH 2
FRONT PANEL
LED CONNECTION
BRAKE
CONNECTOR
CHARGE +
BATTERY POSITIVE BATTERY NEGATIVE
MOTOR 2
MOTOR 1
HINGE DATA
(GREY CABLE)
+24V FUSED
INFRARED/
RADIO
NO CONNECTION
REQUIRED
DIP SWITCH 1
(BLACK)
(WHITE)
DIAGNOSTIC
DISPLAY
EXTERNAL DIAGNOSTIC
JUMPER MUST
BE PRESENT
ON CONNECTOR
9 WAY CONNECTOR8 WAY CONNECTOR
ON
ON
WHITE BLUE BROWN BROWN N/C N/C GREY YELLOW N/C N/C ORANGE ORANGE YELLOW YELLOW WHITE N/C WHITE
5A
QUICK BLOW
ON
1 2 3 4
ON
1 2 3 4
SLIDE ENABLE PING ENABLE PLATFORM ENABLE AUTO HINGE ENABLE RIGHT HAND LIFT FAST RAMP UNUSED
2 PID1 PID
DEFAULT OFF
SLIDE DISABLE
PING DISABLE
PLATFORM DISABLE
AUTO HINGE DISABLE
LEFT HAND LIFT
SLOW RAMP
UNUSED
DIP SWITCH SETTING CSE125SM
DIP SWITCH SETTING CSE126
ON
1 2 3 4
THIS SETTING WILL ENABLE POWER SWIVEL MODE
MS125 2000 DIP Settings RH Auto Swivel System
1 2 3 4
1 2 3 4
IF ANY DIP SWITCHES ARE CHANGED, PLEASE
TURN OFF LIFT, WAIT 10 SECONDS, THEN
POWER THE LIFT BACK ON.
INFRARED/RADIO
LEARN BUTTON
DIP SWITCH 2
FRONT PANEL
LED CONNECTION
BRAKE
CONNECTOR
CHARGE +
BATTERY POSITIVE BATTERY NEGATIVE
MOTOR 2
MOTOR 1
HINGE DATA
(GREY CABLE)
+24V FUSED
INFRARED/
RADIO
NO CONNECTION
REQUIRED
DIP SWITCH 1
(WHITE)
(BLACK)
DIAGNOSTIC
DISPLAY
EXTERNAL DIAGNOSTIC
JUMPER MUST
BE PRESENT
ON CONNECTOR
9 WAY CONNECTOR8 WAY CONNECTOR
ON
ON
WHITE BLUE BROWN YELLOW N/C N/C GREY VIOLET N/C N/C ORANGE ORANGE YELLOW YELLOW WHITE N/C WHITE
5A
QUICK BLOW
ON
1 2 3 4
ON
1 2 3 4
SLIDE ENABLE PING ENABLE PLATFORM ENABLE AUTO HINGE ENABLE RIGHT HAND LIFT FAST RAMP UNUSED
2 PID1 PID
DEFAULT OFF
SLIDE DISABLE
PING DISABLE
PLATFORM DISABLE
AUTO HINGE DISABLE
LEFT HAND LIFT
SLOW RAMP
UNUSED
DIP SWITCH SETTING CSE125SM
DIP SWITCH SETTING CSE126
ON
1 2 3 4
THIS SETTING WILL ENABLE POWER SWIVEL MODE
MINIVATOR 2000 INSTALLATION MANUAL 45
Appendix 3
MS125 2000 DIP settings LH auto swivel system
MS125 2000 DIP settings RH auto swivel system
