34 HANDICARE SIMPLICITY INSTALLATION MANUAL
NOTE: ALL SWITCHES IN STATE WHERE
CHAIR IS IS READY TO DRIVE
KEYSWITCH
SW1
DIRECTION
LH=DN
RH=UP
OPTIONAL
POWER FOOTPLATE
SEAT SWITCH
(950L)
WHITE1
2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
1 2
WHITE
E-STOP
SW4
GREEN
BLUE
ORANGE ORANGE
GREEN
SW2
SW6 SW7
SW8
SW3
SW5
DIRECTION
LH=UP
RH=DN
SWITCH OPEN CIRCUIT = FOOTPLATE DOWN SWITCH CLOSED CIRCUIT = FOOTPLATE UP
ARM INTERLOCK 1
24V
FINAL LIMIT
ESTOP DETECT
DIRECTION
POWER
FOOTPLATE
ARM INTERLOCK 2
1
2
1
2
1
2
1
2
1 2 1 2 3
1 2 3 4
BLUE
WHITE WHITE
YELLOW/BLACK STRIPE
0V 24VDC NO CONNECTION ESTOP/KEY DETECT
RED
BLACK
YELLOW YELLOW
SWIVEL
Simplicity arm interlocks schematic
Appendix 4
