Handlink Technologies WG-500P - Radius 3

WG‐500PHotspotinaPrinter
31

3‐2‐1‐2  RADIUS

Figure3‐2‐4AuthenticationSettingScreen
Item Default Description
RADIUS Authentication Disable Option: No Authentication or RADIUS Server.
Disable (No Authentication)
Subscriber can direct access the Internet without enter username and
password.
Enable (RADIUS Authentication)
WG-500P provides “RADIUS Authentication” for service provider to
build up an Internet service with RADIUS server. If RADIUS
Authentication is enabled, all subscribers’ authentication will send to
RADIUS Server by RADIUS protocol (RFC 2865, 2866).
Time to Finish/
Accumulation

Enable Service provider provides two different accounting calculate for the
Internet service.
Primary RADIUS Server
Server IP Empty Enter the IP address of RADIUS server.
Authentication Port 1812 Enter the authentication port number; the authentication port number
must match with the RADIUS server setting. The allowed numbers
are from 0 to 65535.
