2.3 Display and control
Item
Description
Item
Description
11
Belly switch
15
Horn
12
Forward and backward switch
16
Fork down button
13
password keyboard
17
Fork lifting button
14
Electricity meter
Electricity meter display function
Power display: ten levels display the percentage of remaining power;
Power shortage reminder: flashing reminder when there is 15% remaining power, the frequency is
1 time/second;
State memory: power on after power off, power can be displayed in memory;
Hour meter: digital display of the current accumulated working time of the vehicle, maximum 6
digits display (1 digit after the decimal point); unit: h;
In the CAN version, it can communicate with the electronic control to obtain the power, speed and
fault code; (CAN protocol support required)
12
13
11
17
16
15
14
