HANGCHA Mini Range CDD12-A2MJ-SZ - Hydraulic System

63
2 Hydraulic system
Hydraulic system is mainly composed of hydraulic unit, rubber tube and lifting cylinder.
1. Lifting cylinder
2. Hydraulic unit
3. Multi-way valve
4. tank
5. Hose connector
Figure 2-5 Hydraulic system
1
2
4
3
5
