15
Sensor Inputs
3 for HI7698194
2 for HI7698195 and HI7698196
Sample Environment Fresh, brackish, seawater
Waterproof protection IP68
Operating Temperature
‑5 to 55 °C
Storage Temperature ‑20 to 70 °C
Maximum Depth 20 m (66’)
Dimensions
(without cable)
342 mm (13.5”), dia=46 mm (1.8”)
Weight (with
batteries and sensors)
570 g (20.1 oz.)
Cable Specification
Multistrand‑multiconductor shielded cable with internal strength
member rated for 68 kg (150 lb) intermittent use
Wetted Materials
Body: ABS
Threads: Nylon
Shield: ABS/316 SS
Temp probe: 316 SS
O‑Rings: EPDM
PROBE SPECIFICATIONS
