FUNCTIONAL DESCRIPTION
Range 0.00 to 14.00 pH
±1999 mV
Resolution 0.01 pH / 1 mV
Accuracy (@20°C) ±0.01 pH / ±1 mV
Typical EMC Deviation ±0.03 pH / ±2 mV
pH Calibration Manual, 2 point, through knobs
Temperature Compensation
Manual from 0 to 100°C (32 to 212°F)
pH Electrode (included)
HI 1332B plastic body, double junction,
refillable, with BNC and 1m (3.3') cable
Analog output 0 to 5V
(pH209R only) 0 to 14 pH / -1999 to +1999 mV
Temperature: always 0
Input Impedance 10
12
ohm
Power Supply 12 Vdc adapter (included)
Environment 0 to 50°C (32 to 122°F);
RH max 95% non-condensing
Dimensions 240 x 182 x 74 mm (9.4x7.2x2.9")
Weight approx. 1.0 kg (2.2 lb.)
SPECIFICATIONS
1) Liquid Crystal Display (LCD)
2) pH slope adjustment knob
3) pH offset adjustment knob
4) pH range selection key
5) mV range selection key
6) °C range selection key
7) Temperature setting knob
8) ON/OFF switch
9) Power adapter socket
10) BNC electrode connector
11) Electrode reference socket
12) Analog output (PH209R only)
