User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 43.2cm(17.0")
Pixel pitch 0.264mm(H) x 0.264mm(V)
Video
R,G,B Analog Interface
Digital (Dual-Input Model) H/V TTL
Input H-Frequency 31KHz – 80KHz
V-Frequency 55 – 75Hz
Display Colors 16.2M Colors
Max. Resolution 1280 x 1024 @75Hz
Plug & Play VESA DDC2B
TM
ON Mode ≤36.7W
EPA ENERGY STAR
®
OFF Mode ≤2W
Audio output Rated Power 1.5W rms (Per channel)
Input Connector
D-Sub 15pin
DVI-D 24pin (Dual-Input Model)
Maximum Screen Size
Hor. :337.92mm
Ver. : 270.34mm
Power Source 100~240VAC,50/60HZ
Environmental
Considerations
Operating Temp: 0° to 50°C
Storage Temp: -20° to 60°C
Operating Humidity: 20% to 80%
Dimensions
368(W)×380 (H)×210(D) mm
14.5”(W)×15”(H)×8.3”(D)
Weight (GW/NW)
5.0 kg / 3.8 kg
11.0 lb / 8.38 lb
***The above specification is subject to actual panel specification and is subject to change
without prior notice.
22
