User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 22” (21.6" Viewable)
LCD Panel
Pixel pitch 0.276mm(H) x 0.276mm(V)
H-Frequency 30KHz – 80KHz
Video
V-Frequency 50 – 75Hz
Display Colors 16.7M Colors
Max. Resolution 1680 x 1050 @75Hz
Plug & Play
VESA DDC2B
TM
ON Mode
≤50W
EPA ENERGY STAR
®
OFF Mode
≤1W
Audio output Rated Power 1 W rms (Per channel)
Input Terminal
D-Sub
HDMI (Dual-Input Model)
Maximum Screen Size
Hor. : 464.947mm
Ver. : 290.58mm
Power Source 100~240VAC,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity: 20% to 90%
Dimensions
518 (W) x 412(H) x 230(D) mm
20.3 ”(W)×16.2 ”(H)×9.0 ”(D)
Weight (NW) 5.8 kg (12.77 lb)
***The above specification is subject to actual product specification and is subject to
change without prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can
refer to
www.hannsg.com FAQ section.
21
