User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 19"
LCD Panel
Pixel pitch 0.294mm(H) x 0.294mm(V)
H-Frequency 24KHz – 80KHz
Video
V-Frequency 56 – 75Hz
Display Colors 16.7M Colors
Max. Resolution 1280 x 1024 @75Hz
Plug & Play
VESA DDC2B
TM
, DPMS
ON Mode 35W (Typical)
Power Saving Mode ≤1W
Power consumption
OFF Mode ≤0.5W
Audio output Rated Power 1.0W rms (Per channel)
Input Terminal
VGA
DVI
Maximum Screen Size
Hor. : 376.32mm
Ver. : 301.056mm
Power Source 100~240VAC,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 0° to 35°C
Storage Temp.: -20° to 60°C
Operating Humidity: 20% to 85%
Dimensions
410.0 (W) x 411.0(H) x 160.1(D) mm
16.1 ”(W)×16.2 ”(H)×6.3 ”(D)
Weight (NW) 4.0 kg(8.8lb)
*** The above specification is subject to actual product specification and is subject to change
without prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can refer to
www.hannsg.com FAQ section.
