PC Mode Support Timing
Video Mode Support Timing
Mode Resolution
(active dot)
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
Nominal
Pixel
Clock
(MHz)
VGA DVI
to
HDMI
VGA 640x480@60Hz 31.469 59.941 25.175 V V
SVGA 800x600@60Hz 37.879 60.317 40.000 V V
XGA 1024x768@60Hz 48.363 60.004 65.000 V V
VESA 1152x864@75Hz 67.5 75 108 V V
VESA 1280x720@60Hz 44.955 59.940 74.176 V V
VESA 1280x960@60Hz 60 60 108 V V
SXGA 1280x1024@60Hz 63.981 60.020 108.000 V V
VESA 1366x768@60Hz 47.712 59.790 85.500 V V
Resolution
(active dot)
HDMI YPbPr
640x480p@60Hz V V
720x480i@60Hz V V
720x480p@60Hz V V
1280x720p@60Hz V V
1920x1080i@60Hz V V
1920x1080p@60Hz V V
1920x1080p@24Hz V V
1920x1080p@30Hz V V
