DG3 Controller – Installation and Operation Manual
540846-3 page 61 of 64 25/09/2015
* = use of driver's controller display text from
Helen
0 - 7 = show content from selected sign on
driver’s display
Determines what is shown on driver's controller display
0 = use of only the top line of the controller
screen
1 = use of the top two lines of the controller
screen
2 = attempts a 'best-fit' of driver's message
within controller screen (if necessary, by re-
sizing)
T = shows time in hours, mins, secs (24h
clock) - where clock is enabled
T12, T12S, T24, T24S = displays (12h / 24h)
clock without / with seconds - where clock is
enabled
Controls how driver's message is displayed on the controller screen
In standard destination mode: it controls if
destination information and numbers are shown on the passenger signs and
destination codes can be viewed and changed on the controller.
In route browse mode: this feature has no effect.
DS –
Destination
Code Size
Controls the size of the destination code shown on the controller screen; it can be
set from 3 to 6 digits.
0 = does not require lock code
Adverts are shown on passenger signs and the advert code is shown on the
controller screen. This feature controls whether changing the advert code requires
the lock code.
0 = does not require lock code
Information are shown on passenger signs and the information code is shown on
the controller screen. This feature controls whether changing the information code
requires the lock code.
-, 1, 2 … 10, IN, INI, DV, DVI, BR, BRI
Please refer to section External inputs I0 and I1: emergency message, bus
reversing, bus stopping, battery guard, information message or Hanvox message.
-, 1, 2 … 10, IN, INI, DV, DVI, BR, BRI
Please refer to section External inputs I0 and I1: emergency message, bus
reversing, bus stopping, battery guard, information message or Hanvox message.
