EN-15
HFD17690EI
Preparing the appliance
Attaching the door handles
The appliance is supplied with four door han-
dles,
– two for the fridge
– two for the freezer.
The door handles can be distinguished by the
size of their curve. The handles for the freezer
have a more arched curve.
1. Screw the 8 supplied bolts 14 into the doors
using a cross-head screwdriver.
14
16
15
2. Place the door handles 16 onto the bolts 14.
3. Tighten the fixing screws 15 by turning them
clockwise with the supplied hex key.
Fitting the hinge cover
• Attach the hinge cover to the base of the ap-
pliance using the 3 supplied screws.
