Product introduction
EN
HDG3000B Quick Guide Copyright © Qingdao Hantek Electronics Co., LTD
10
4.2 Rear panel introduction
Figure 4.2 Rear panel
5 Counter (0 to 3.3V,
external signal input)
6 USB DEVICE port
7 Safety keyhole
8 AC power jack
4.3 User interface introduction
Figure 4.3 User interface
1 Selected channel
4 Channel configuration
2 Channel parameters
5 Menu
3 Waveform
