SKU 93662 For technical questions, please call 1-800-444-3353. Page 9
HOSE
COUPLING
COUPLING
GASKET
HOSE
JOINT
HOSE
CLAMP
2” DIAMETER
INTAKE HOSE
(NOT INCLUDED)
HOSE
CLAMP
INTAKE
FILTER
(21)
HOSE
COUPLING
COUPLING
GASKET
HOSE
JOINT
2” DIAMETER
DISCHARGE HOSE
(NOT INCLUDED)
HOSE
CLAMP
DISCHARGE FLANGE
(10)
INTAKE FLANGE
(14)
FIGURE C
