Part Description Q’ty
98 M5x0.8x8mm Set Screw 4
99 Lead Screw 2
100 Column 3
101 Lead Screw 1
102 Column 1
103 Scale 1
104 Base 1
105 3AM1x30 Retaining Ring 4
106 6000ZZ Ball Bearing 4
107 Bearing Retainer 4
108 Spacer 4
109 Sprocket 4
110 Flat Washer M4 4
111 M4x0.7x12mm Pan Head Screw 4
113 M5x0.8x10mm Bolt w/Lock
Washer
12
114 Idler Bracket 1
115 5mm Flat Washer 2
116 M5x0.8x10mm Socket Head Bolt 2
117 Sprocket 1
118 Spacer 1
119 1/4” Flat Washer 1
120 M6x1.0x20mm Pan Head Screw 1
121 Chain 1
122 Hex Wrench 4mm 1
123 Magnet 2
127 Gasket 1
128 Rod 1
129 M4x0.8x10mm Socket Head Bolt 2
130A M5x0.8x10mm Socket Head Bolt 1
130B 1/4” Flat Washer 1
131 Lead Screw 1
145 Carton Label 1
146 Logo 1
147 Lock Washer M4 4
150 Motor Assembly (includes key
1
Part Description Q’ty
151 M5x0.8x20mm Pan Head Screw 3
152 Lock Washer M5 3
153 Housing (Left) 1
154 Gasket 1
155 Circuit Breaker 1
156 Strain Relief Bushing 1
157 Line Cord 1
158 Wire Connector 1
159
Screw
1
160 Switch 1
161 Switch Frame 1
162 Switch Cover 1
164
Screw
3
165 Lock Washer M5 3
166 Motor Cover 1
167 1 1/4” Wavy Washer 1
168 2
169
Screw
1
170 Ground Wire 1
171 5mm Serrated Washer 1
172 Armature 1
173 Insulating Sleeve 1
174 Stator 1
175
Screw
2
176 Lock Washer M5 2
177 Logo Label 1
178 Housing (Right) 1
179 Pivot Rod 1
180 Brush Holder 2
181 Brush 2
182 Brush Cap 2
183 M5x0.8x10mm Set Screw 1
184 1
PARTS LIST (CONTINUED)
NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as
replacement parts.
Rev 10d
To Next Page
