SKU 95082 For technical questions, please call 1-800-444-3353. Page 16
PARTS LIST
Part Description Q’ty
1 Left Cap 1
2 Dowel Pin 4
3 Bushing 4
4 Roller 2
5 Cap 1
6 M5x0.8x25mm Bolt w/Lock
Washer
1
7 Knob 1
8 Screw 1
9 Knob Housing 1
10 Handle 1
11 Right Cap 1
12 M6x1.0x6mm Pan Head Screw 4
13 Grip 2
14 Blade Guard 1
15 Air Duct 1
16 M5x0.8x10mm Socket Head Bolt 4
17
Screw
3
18 3AM1x15 Retaining Ring 1
19 Chain 1
20 Sprocket 1
21 Spacer 1
22 M5x0.8x30mm Socket Head Bolt 1
23 M5x0.8x35mm Socket Head Bolt 3
24 M5x0.8x27mm Socket Head Bolt 2
25 1
26 6002ZZ Ball Bearing 1
27 Shaft 1
28
Screw
4
29 Cord Wrap Frames 2
30 Side Cover 1
31 M6x1.0x12mm Pan Head Screw 5
32 58T/12T Double Gear 1
33 70T Gear 1
34 Spacer 2
35 Inside Gear Plate 1
36 52T/12T Double Gear 1
37 Bushing 5
38 Spacer 4
39 Pinion 1
40 6203ZZ Ball Bearing 1
41 M5x0.8x8mm Pan Head Screw 2
42 Serrated Washer M5 2
43 Spacer 1
44 M5x0.8x8mm Set Screw 1
45 M5x0.8x10mm Pan Head Screw 1
46 Cable Clamp 1
47 Roller Case 1
48 M5x0.8x10mm Socket Head Bolt 2
Part Description Q’ty
49 Belt Guard 1
50 M5x0.8x12mm Socket Head Bolt 8
51 Flat Washer M8 1
52 M8x1.25x20mm Hex Head Bolt 1
53 Cutterhead 1
54 Pin 4
55 M6x1.0x16mm Pan Head Screw 12
56 Gib 2
57 Blade (set of 2 ) 2
58 Spring 4
59 M5x5x10mm Key 1
60 Motor Pulley 1
61 6203ZZ Ball Bearing 1
62 Bearing Retainer 1
63 M5x0.8x10mm Socket Head Bolt 3
64 Cutterhead Pulley 1
65 1
66 Indicator 1
67 1/4” Flat Washer 1
68 M6x1.0x12mm Pan Head Screw 5
69 Fan 1
70 1/4” Flat Washer 1
71 M6x1.0x12mm Pan Head Screw 1
72 Fan Cover 1
73
Screw
5
74 Fan Shaft 1
75
Screw
3
76 Dust Guide 1
77 1
78 Fan Housing 1
79 M6x1.0x25mm Pan Head Screw 1
80 Dust Chute 1
81 3AM1x15 Retaining Ring 2
82 Sprocket 1
83 Chain 1
84 2
85 1
86 Infeed Spring 2
87 Infeed Roller 1
88 Sprocket 2
89 Retaining Bracket 4
90 Left Bracket 2
91 M5x0.8x10mm Socket Head Bolt 4
92 Right Bracket 2
93 M5x0.8x10mm Socket Head Bolt 4
94 Guide 2
95 Table 1
96 M5x0.8x10mm Socket Head Bolt 8
97 Lead Nut 4
