Harbor Freight Tools Predator 9500 - Engine Parts List

Page 24
For technical questions, please call 1-888-866-5797.
ITEM 57080
SAFETY OPERATION MAINTENANCESETUP
Parts List - Engine
Part Description Qty
1A
Hex Flange Bolt /M6*1
8
2A
Cylinder Head Assembly
1
3A
Cylinder Head Gasket
1
4A
Clamp Φ14*Φ15.5*10
1
5A
Waste Pipe
1
6A
Nut/M6xp0.75
2
7A
Rocker Shaft
2
8A
Rocker Arm
2
9A
Rocker Shaft Bolt
2
10A
Exhaust Valve Rotor
2
11A
Exhaust Valve Spring Seat
2
12A
Spring, Valve
2
13A
Exhaust Valve Spring Lower Seat
2
14A
Oil Seal
2
15A
Push Rod Guide
1
16A
Cylinder Head
1
17A
Hex Flange Bolt /M10*1.25
4
18A
Spark Plug Component
1
19A
Bolt,Stud,Exhaust
2
20A
Bolt, Stud, Inlet
2
21A
Spark Plug Rubber Cover
1
22A
Hex Flange Bolt /M6*1
14
23A
Shroud
1
24A
Air Inlet Gasket
1
25A
Carburetor Connector Block
1
26A
Carburetor Washer
1
27A
Carburetor
1
28A
Wire Clamp
1
29A
Clamp
1
30A
Tube, Fuel
1
31A
Wire Clamp
1
32A
Tubing Sleeve
1
33A
Gasket, Air Cleaner
2
34A
Carburetor Cable Support
1
35A
Air Filter
1
36A
Cylinder Head Gasket
1
37A
Locating Pin/Φ 10 * 12 * 20 Φ
2
38A
Push Rod
2
39A
Valve, Exhaust
1
40A
Valve, Intake
1
41A
Lifter, Valve
2
42A
Ring Set, Piston
1
43A
Clip, Piston Pin
2
44A
Piston
1
45A
The Piston Pin/Φ Φ 15 20 * * 62
1
46A
Connecting Rod Assy
1
47A
Hex Flange Bolt /M12*1.5
2
Part Description Qty
48A
Aluminum Washer
2
49A
Crankcase
1
50A
Metal Clip
1
51A
Oil Alert
1
52A
Speed Governor
1
53A
Metal Clip
1
54A
Oil Seal
2
55A
Coil Assembly, Ignition
1
56A
Hex Flange Bolt/M8*1.25
2
57A
Flywheel Part
1
58A
Charging Coil Unit
1
59A
Hex Flange Bolt /M6*1
2
60A
Wire Press Plate
1
61A
Fan
1
62A
Pulley, Starter
1
63A
Hex Flange Nut/M16*1.5
1
64A
Recoil Starter Assembly
1
65A
Deep Groove Ball Bearing
2
66A
Hex Flange Bolt/M6*1
2
67A
Engine Oil Sensor
1
68A
Balance Shaft
1
69A
Camshaft
1
70A
Crankshaft
1
71A
Cylinder Head Air Guide Sealing Strip
1
72A
Clamp Part
1
73A
Cross Recessed Countersunk Screw
4
74A
Clamp Part
1
75A
Cylinder Head Air Guide Sealing Strip
1
76A
Crankcase Cover
1
77A
Hex Flange Face Bolt/M8x1.25
17
78A
Crankcase Cover Baffle
1
79A
Oil Gauge Assembly
1
80A
Deep Groove Ball Bearing
1
81A
Dowel Pin
4
82A
Crankcase Cover Gasket
1
83A
Nut With Flange/M18*1.5
2
84A
Starting Motor
1
85A
Nut With Flange/M6x1.0
2
86A
Fan
1
87A
Inverter Rotor
1
88A
Flat Washer/Φ18.5*Φ36.5*5
1
89A
Nut With Flange/M18x1.5
1
90A
Hex Socket Cap Screw
4
91A
Inverter Stator
1
92A
Locating Pin
4
93A
Endcover
1
94A
Alternator Cover Plug
1
When ordering replacement parts from this list, the “A” suffix must be included in order to get the correct part.
