101
8 - Technical specifications
Dimensions
General Info
All dimensions, values and weights are depending on mounted options and specific adjustments.
Overall Dimensions
*Dimension with 36m B3
A - Total length, m 7.60*
B - Total width, m 3.41*
C - Total height, m 3.38*
D - Draw to axle, m 5.46*
D
