3 - Description
16
View
Identification plates
An identification plate fitted on the frame indicates producer name,
model, own weight, max height, max pressure of the hydraulic system (if
fitted) and max pressure of the spray liquid system.
25. Rinsing tank
26. Main tank
27. Hose reel for External Cleaning Device
28. ChemLocker with FoamMarker tank
29. CycloneFilter
30. Support leg storing position
