HARDY MANUFACTURING CO., INC (MODEL H25) PAGE 12
Section II 2-8 Filling the Heater with Water (continued)
THE HEATER MUST BE FILLED WITH WATER BEFORE STARTING A FIRE.
There is a low water switch located in a fitting on the back if the heater. This low water
switch operates a low water warning light and automatic water fill solenoid.
Heater with Hull installed
Insulation
Stainless Steel Trim
Condenser Stack insert’s into
condenser tank. Do not seal
between the condenser stack
and condenser tank.
Seal between the
condenser tank and
the heater hull
Smoke stack and collar
Seal between the collar around the
smoke stack and the outer hull
To Next Page
