NOTE
The figures listed above assume that the battery is charging
at room temperature. If warmer than room temperature, use a
slightly shorter charging time. If colder, use a slightly longer
charging time.
NOTE
The use of constant current chargers to charge sealed main-
tenance-free batteries is not recommended. Any overcharge
will cause dry-out and premature battery failure. If a constant
current charger is the only type available, do not exceed the
charge times listed above and do not continue charging the
battery if it gets hot. When charging, never exceed 15 volts for
more than 30 minutes.
Table 1-2. Battery Charging Rates/Times (Approximate)
BATTERY
AMP HOUR
STATE OF CHARGE
3 AMP
CHARGER
6 AMP
CHARGER
10 AMP
CHARGER
20 AMP
CHARGER
VOLTAGE % OF CHARGE
VRSC,
SPORTSTER
12
12.8 100% ----
12.6 75% 70 minutes 34 minutes 20 minutes 10 minutes
12.3 50%
2 hours,
20 minutes
70 minutes 40 minutes 20 minutes
12.0 25%
3 hours,
20 minutes
1 hour,
40 minutes
1 hour 30 minutes
11.8 0%
4 hours,
30 minutes
2 hours,
14 minutes
1 hour,
20 minutes
40 minutes
DYNA,
SOFTAIL
18
12.8 100% ----
12.6 75% 1.75 hours 50 minutes 30 minutes 15 minutes
12.3 50% 3.5 hours 1.75 hours 1 hour 30 minutes
12.0 25% 5 hours 2.5 hours 1.5 hours 45 minutes
11.8 0%
6 hours,
40 minutes
3 hours,
20 minutes
2 hours 1 hour
TOURING
28
12.8 V 100% - - - -
12.6 V 75% 2.5 hours 1.25 hours 45 minutes 25 minutes
12.3 V 50% 5 hours 2.5 hours 1.5 hours 50 minutes
12.0 V 25% 7.5 hours 3.75 hours 2.25 hours 70 minutes
11.8 V 0% 10 hours 5 hours 3 hours 1.5 hours
