1-18 2005 PDI: All Models
WARNING LABEL PLACEMENT
(ALL VEHICLES SOLD OUTSIDE OF
THE UNITED STATES)
All dealers outside of the United States are required to apply
a warning label to the vehicle in the local language of the cus-
tomer. A sheet of warning labels (Part No. 99942-05) is pro-
vided in the Owner’s Kit.
Apply the appropriate local language version of the warning
label as required to suit your local market. If your local lan-
guage is not represented on this label sheet, use the English
language label.
All EFI Big Twin Models
See Figure 1-30. Peel appropriate label from sheet. Apply
label on top of air cleaner cover, centered on cover and lined
up with edge of air cleaner back plate.
All Carbureted Big Twin Models
See Figure 1-31. Peel appropriate label from sheet. Apply
label on top of air cleaner cover, centered on cover and lined
up with edge of carburetor cutout in air cleaner back plate.
All Sportster Models
See Figure 1-32. Peel appropriate label from sheet. Apply
label on top of air cleaner cover, centered on cover and lined
up with edge of air cleaner back plate.
All VRSC Models
See Figure 1-33. Open seat. Peel appropriate label from
sheet. Apply label centered on rear end of air cleaner cover
with bottom edge of label 1.0 in. (25.4 mm) from rear edge of
air cleaner cover.
Figure 1-30. Warning Label Placement–
All Big Twin EFI (Typical)
Figure 1-31. Warning Label Placement–
All Big Twin Carbureted (Typical)
10683
10684
Figure 1-32. Warning Label Placement–
All Sportster Models (Typical)
Figure 1-33. Warning Label Placement–
All VRSC Models (Typical)
10685
10686
1.0 in
(25.4 mm)
